19
6
1113
05306004
Page
Notice
Date
INSTALLATION
MANUAL
Table 4
(B2, C and E correction factors for cable grouping)
B2 C E
Number Seated in Wall Fixing Cable Tray
of Cables Cable Duct or Cable Trough
1 1,00 .........................1,00 ..............................1,00
2 0,80 .........................0,85 ..............................0,87
4 0,65 .........................0,75 ..............................0,78
6 0,57 .........................0,72 ..............................0,75
9 0,50 .........................0,70 ..............................0,73
The total current included for using Table 1 should be the maximum rated current for the ma-
chine divided by the product of the different correction factors. Other correction factors may
also be applied ; consult the cable manufacturers.
Calculation : Example
- The machine has a rated current of 60 A.
- The ambient temperature is 45 °C ; Table 2 gives a correction factor of 0.91.
- Cable with rubber insulation : Table 3 gives a correction factor of 0.92.
- The cable is xed directly to the wall (Column C), with 2 cables side by side. Table 4 gives a
correction factor of 0.85.
60 A
Total current : ----------------------- = 84 A
0,91 x 0,92 x 0,85
Taking Column C in Table 1 (wall xing), we obtain a minimum cable section of : 3 x 25 mm².
Machine Heating Supply Installed Rated Main Connection
type voltage electrical intensity switch cable Fuse
power section
FC48 Gas/Steam 380/415 V 3+E ~ 50/60 Hz 1.8 kW 3.5 A 3 x 12 A 4 x 2.5 mm² 3 x 12 A
FC48 Gas + boiler 380/415 V 3+E ~ 50/60 Hz 7.8 kW 13.7 A 3 x 16 A 4 x 2.5 mm² 3 x 16 A
FC48 Steam + boiler 380/415 V 3+E ~ 50/60 Hz 7.8 kW 13.7 A 3 x 16 A 4 x 2.5 mm² 3 x 16 A
FC48 Electric 380/415 V 3+E ~ 50/60 Hz 19.8 kW 30 A 3 x 40 A 4 x 6 mm² 3 x 40 A
FC48 Elec. + boiler 380/415 V 3+T ~ 50/60 Hz 25.8 kW 40 A 3 x 50 A 4 x 10 mm² 3 x 50 A
6. Installation/
Putting into service
