14
DOOR REMOVAL
CAUTION
The drawer is heavy. Use caution when lifting.
Removing the Freezer Drawer
1. Remove the 4 hex head drawer screws
(2 per side) that secure the drawer to
the slide assemblies.
2. Lift the drawer up to remove it.
Remove
Hex Head
Drawer
Screw
CAUTION
Do Not loosen or remove the 3 hex screws.
NOTE
To locate the pin, look inside the drawer. The
pin is next to the door liner and the slides.
Not all parts are shown in the illustration.
Replacing the Freezer Drawer
1. Extend the freezer slides from the unit.
2. Carefully align the support pin with the
hooks on end of the freezer slides,
and then lower the freezer door onto
the slides.
3. Replace the 4 hex head screws that
secure the slides to the door (2 on
each side) and tighten.
