Installation manual
19
3.2 Technical data
Weight, net kg
lbs
440
970
Drum volume litres
ft
3
2 x 423
2 x 15
Drum diameter
mm
inch
832
32 3/4
Drum depth
mm
inch
757
29 13/16
Drum speed
rpm
43–44
Rated capacity, filling factor 1:18 (Max. load) kg
lbs
2 x 23.5
2 x 51.8
Rated capacity, filling factor 1:22 (Recommended load) kg
lbs
2 x 19.2
2 x 42.3
Heating: Gas kW
Btu/hr
2 x 27.5
94,000
Airborne sound level dB(A) 70
Air flow m
3
/h
cubic feet per minute
2 x 850
2 x 500
Duct connection, exhaust
⌀ mm
⌀ inch
1 x 200
1 x 8
Maximum static back pressure, Gas 50 Hz / 60 Hz** Pa
WC
340 / 520
1.36 / 2.09
Gas pipe connection 3/4” MNPT
Sound power/pressure level at drying* dB(A) 77/60
Heat emission of installed power, max % 15
* Sound power levels measured according to ISO 60704.
** Static back pressure value measured in NTC position of bottom pocket only, in cold empty machine and running a
program with no heat on both pockets at the same time.
Note!
This gas appliance is built to run on either GNH or LPG gas.
This default gas appliance is built to be installed up to an altitude of 610 m (2001 ft).
If installing above this altitude a kit for high altitude must be installed on the machine.
For kit No. please refer to the spare parts list.
For LPG use gas qualities according to GPA Midstream Standard 2140-23.
