ZLX-G2 Full-range loudspeaker Recommended configurations | en 39
Bosch Security Systems, LLC
User manual
2024-03 | 02 |
ZLX-12P-G2 ELX200-18SP
Low Pass: n/a ZLX-12P-G2
Table9.6: DSP settings loudspeaker and subwoofer stacked
9.2 Passive loudspeakers
!
Caution!
For optimal acoustics and performance, we recommend using the ZLX-G2 with a Dynacord
DSP power amplifier, programmed with the appropriate speaker settings included in the EV
Speaker Database for SONICUE. Failure to use the proper amplifier and speaker settings
may result in poor acoustic performance, cause permanent damage, and void of warranty.
9.2.1 Basic stereo system using full-range systems
The configuration includes:
– ZLX-8-G2, ZLX-12-G2 or ZLX-15-G2 loudspeakers.
– Dynacord L1800FD amplifier programmed with the appropriate speaker settings from
SONICUE.
Input A
Input B
Output AOutput B
NL4 Pin Configuration
Pin 1+ and 1- Used
Pin 2+ and 2- Not used (pass-through)
