ZLX-G2 Full-range loudspeaker Input & Mixer operation | en 31
Bosch Security Systems, LLC
User manual
2024-03 | 02 |
24V (INPUT 1 only)
+24V DC phantom power is available on the XLR connector of INPUT1 only. Phantom power
can be used to power certain devices such as DI boxes and condenser microphones (non-
electret). Consult the user manual of your device before using. There is no phantom power
on the TRS connectors. Phantom power is switchable.
i
Notice!
Switch off phantom power (default) for sources which do not require phantom power such
as dynamic microphones and mixer outputs.
i
Notice!
Never connect a mobile device to INPUT1 with phantom power activated.
PRESET
The input PRESET adjusts the EQ and compressor settings to provide a starting point for
adjusting the sound for different input types.
COMP control
The COMP control controls the onboard compressor to adjust the input signal processing
during operation. Compressors are available on INPUT1 and INPUT2.
4 Use the COMP control to adjust the compressor threshold and the compression ratio
simultaneously.
Adjusting the COMP control from 0 to 100 will result in the following:
– The gain below the threshold will increase from 0dB to +6dB.
– The compression ratio will increase from 1:1 to 8:1.
– The compressor will reduce the dynamic range of the audio signal proportional to the
compressor setting.
Once the signal exceeds a certain threshold, the signal gets compressed. Major input level
changes result in minor output level changes. Narrowing the dynamic range often allows for
easier recording or mixing of the audio signal. It is recommended to start with low to
moderate levels of compression (25 - 40) and increase slowly if necessary.
TREBLE/MID/BASS controls
The EQ section of the input channel allows for a broad difference in the shaping of the
incoming audio signal within three frequency bands:
– TREBLE control - provides cymbals and vocals with more treble for a more transparent
sound.
– MID control - increasing this level provides higher output in the vocal range, reducing
this level can help reduce acoustical feedback.
– BASS control - adds more “punch” to the sound of a kick drum or adds “body” to the
vocals.
FX
The FX control is used to set the amount of effect you require on that channel. Using the FX
controls lets you easily assign an effect for musical instruments or vocals.
