Page 3
Installation
To avoid hum in the output, be certain that all input cables are physically
separated from power wiring and transformers. Speaker cables should
also be kept away from input cables and power cables.
An example of what sources and output devices would be connected to
this unit is shown in Figure 1.
Grounding
Ground the chassis of the unit by using the ground terminal located on
the back panel. For the best grounding, connect the amplifier to an earth
ground such as a cold water pipe or ground rod. If additional equipment
is installed along with the amplifier, make sure their chassis are
connected together to reduce noise and hum.
Ventilation
To remove the heat generated by the power amplifier, provide ample
ventilation around the unit. Avoid blocking or impeding the vent slots in
the cabinet.
Locate the unit where it is free from direct sunlight, humidity, dust and
vibration.
Key Input Connections
Microphones. The Mic inputs are for use with balanced Low Impedance
(approximately 200 ohms) or unbalanced high impedance
(approximately 20k ohms) microphones. For high impedance
microphones, cables should be as short as possible in order to avoid
loss of High Frequency response. The results will vary with the
microphone and cable capacitance. However, a limit of 30 feet is
recommended.
The Mic inputs may be accessed by either XLR connectors or ¼ phone
plugs.
Figure 2 shows the wiring configurations of both unbalanced and
balanced microphones using either ¼ or XLR type connectors.
