30 en | Input & Mixer operation EVOLVE 70/90 Portable Column Loudspeaker
2025-03 | 01 |
User manual
Bosch Security Systems, LLC
PAN
The PAN control adjusts the amount of the signal coming out of the stereo L or stereo R
loudspeaker in a stereo setup. The PAN is not engaged for mono (single loudspeaker)
setups.
DUCKER
The DUCKER reduces the level of the signal(s) on all stereo inputs whenever a signal is
detected at the selected MIC/LINE input (INPUT 1 or INPUT 2). If no signal is detected at
the selected MIC/LINE input, the level of the signal(s) on the stereo inputs will return to the
previous set levels.
The DUCKER is useful to speak over background music:
– When signal is detected on the selected MIC input, the music on the stereo input
channels will be reduced.
– When signal is no longer detected on the selected MIC input, the music will return to
the previous level.
Engaging the DUCKER
To engage the ducker:
1. Select INPUT1 and/or INPUT2.
2. Adjust the DUCKER level to set the detection threshold for the selected input channel.
When signal is detected on the selected input, the signal on the stereo inputs will be
reduced by 12dB. Typical values are -10 to -20dB.
The table below describes the DUCKER operation logic. The DUCKER setting is the
detection threshold selected on INPUT 1 and/or INPUT 2. The ducked channels are the
input signals that are reduced by 12dB.
INPUT 1 INPUT 2 Reduced channels
DUCKER SETTING -1dB - -40dB OFF INPUT3 to INPUT8
OFF -1dB - -40dB INPUT3 to INPUT8
-1dB - -40dB -1dB - -40dB INPUT3 to INPUT8
OFF OFF NONE
