Introduction
The EVID-S12.1 subwoofer, from Electro-Voice, is a compact, high-performance, dual voice coil
loudspeaker with outstanding performance for the most demanding professional and
commercial sound applications. Designed and engineered for use in background and
foreground music, and sound reinforcement applications, the EVID-S12.1 subwoofer is the
ideal solution for indoor applications, such as restaurants, bars, patios, retail, fitness clubs,
hospitality, theme parks, leisure venues, and others. The EVID-S12.1 subwoofer is the perfect
solution for a wide variety of surface mount applications.
The EVID-S12.1 subwoofer comes with a dual mode mounting bracket that enables the unit to
be easily mounted at either a wall/wall (corner) or on a wall/ceiling (mid-wall) junction. The
included forged steel eyebolt provides the installer a solid attachment point for a safety line.
The EVID-S12.1 subwoofer may also be safely installed protruding just 2-3/4" down through a
standard suspended ceiling grid.
Read through this manual to familiarize yourself with the safety information, features, and
applications before you use these products.
System features
▪ High-excursion 12" woofer with dual voice coil to accommodate L & R channels
▪ 200 W power handling provides for 127 dB maximum SPL (133 dB Peak)
▪ Crossover input panel included
Product information
A
B
C
E
D
Figure 2.1: Product information
Item
Description
A Dual-mode mounting bracket
B Acoustic ports
C Bracket clip mounting points
D Safety line attachment eyebolt
E Input/output connector panel
Table 2.1: Product information
2
2.1
2.2
en 5
Electro-Voice Installation manual 2017.08 | 01 | F.01U.347.028
