EVID Ceiling Speaker Systems Table of contents | en 3
Electro-Voice
Installation manual
2023-07 | 12 | F.01U.177.705
Table of contents
1
Safety 4
1.1 Notices 4
2
Welcome 5
2.1 Important Features 5
3
System overview 6
3.1 Model Summary 6
3.2 Packing list 7
3.3 Product Feature Identification 8
4
Installation and Wiring 10
4.1 Step 1 — Cut the Hole 11
4.2 Step 2 — Install C-Ring and/or Tile Rails 11
4.3 Step 3 — Attach Wiring to the Terminal Connector 12
4.4 Step 4 — Secure the Cable to the Speaker 14
4.5 Step 5 — Mount the Speaker into the Ceiling 15
4.6 Step 6 — Connect an Auxiliary Support Line 16
4.7 Step 7 — Adjust Tap Selector 17
4.8 Step 8 — Attach the Grille 18
5
Troubleshooting 19
6
Technical data 20
7
Appendices 24
7.1 Appendix A — Painting the Speaker 24
7.2 Appendix B — System Design Guide 24
7.2.1 Selecting and Positioning Ceiling Loudspeakers 24
7.2.2 Ceiling Systems: Size vs. Coverage 25
7.2.3 Use of Subwoofers 27
