9
INSTALLATION OF WINDOW KIT
The window kit (slide bar and shtail adaptor) can be
used with sliding windows and doors. For other
types of windows, the shtail adaptor should be
used on its own.
1.
Slide the rear section of the slide bar onto the front section, lining up the plate so it runs
within the groove. Extend the bar to the required length and use the supplied wing nut to
secure it.
2.
Push the screw thread of the plate through the
hole in the rear of the front slide bar section.
3.
Parally open the window and place the
extended slide bar in posion before closing
the window onto it.
4.
Fix the shtail adaptor into the opening on the
slide bar.
NOTES:
•
The window kit is only designed to be installed with sliding or sash windows or
doors. The window kit is not designed to be used with any other style of windows.
•
The shtail adaptor can be used without the slide bar with most windows/doors.
•
When using the air condioner, ensure that the opening around the shtail adaptor
is as small as possible to ensure the unit's eciency is not reduced.
•
The best form of installaon is through a wall duct. By adequately venng, you expel
hot air from your room while eciently cooling it.
•
Your air condioner should be used without the vent pipe in dry mode. When
using dry mode, ensure that an external water tank is used, monitored and
regularly emptied before overflowing.
Permanent plumbing can also be installed, or
an external upli water pump can be set up to allow
uninterrupted use.
Slide Bar
Slide Bar
(Rear Selection)
Wingnut
