8
INSTALLATION
WARNING: Please keep this unit upright for at least 3-4 hours before using it.
This unit can easily be moved from one room to another. While moving the unit, please note that it must
always be kept upright and then placed on an even surface.
1. Attach the fishtail connector to the end of the hose by
extending the end and twisting until firmly attached (At least
3 full rotations).
2.
Attach the opposite end of the pipe to the exhaust outlet on the rear of
the appliance by putting it into position and twisting until firmly
attached (At least 3 full rotations)
3.
Ensure the unit is upright and there are no obstructions to the air inlets
and outlet grills.
INSTALLATION OF WINDOW KIT
The window kit (slide bar and fishtail) can be used with sliding windows and doors. The fishtail should be used on its
own for other types of windows. You can purchase other types of attachments for different styles of windows. These
will aid in keeping the hot air out of your room in summer but are not necessary.
1. Partially open the window and place the extended slide bar in position before closing the window onto it.
2.
Fix the fishtail adaptor into the
opening on the slide bar
3.
Fix the exhaust connector on
the opposite end of the exhaust
hose to the exhaust outlet on
the rear of the air conditioner.
