14
ELATION© ZCL BAR Z300 IP™ | S Y S T E M M E N U
Features are subject to change without any prior written notice.
MAIN
MENU
SUB MENU
OPTIONS / VALUES (Default Settings in
BOLD)
DESCRIPTION
Set ADDR
Set ADDR
001 ~ 508
DMX Address Setting
UserMode
CH:05, 06, 07, 09, 13, 21, 28
Set DMX Channel / User Mode
Function
DimCurve
Standard, Stage, TV, Architectur, Theatre
Set Dimmer Curve Mode
No DMX
Hold / Blackout / Program
Function If NO DMX Detected
ZOOM
000 - 255
Zoom Control for Auto Run Programs
AUTO RUN
FQN:00-99
Set Number of Times Internal Program Repeats
01.STATC
CL:R, G, B, RG, GB, RB, RGB, BLAC
Internal Program #1
Select COLOR and Adjust FLASH
F: 00-99
02.DREAM
SP:01-99 | F:00-99
Internal Prog#2 Adjust SPEED and FLASH
03.METOR
SP:01-99 | F:00-99
Internal Prog#3 Adjust SPEED and FLASH
04.FADE
SP:01-99 | F:00-99
Internal Prog#4 Adjust SPEED and FLASH
05.CHANG
SP:01-99 | F:00-99
Internal Prog#5 Adjust SPEED and FLASH
06.FLOW1
SP:01-99 | F:00-99
Internal Prog#6 Adjust SPEED and FLASH
07.FLOW2
SP:01-99 | F:00-99
Internal Prog#7 Adjust SPEED and FLASH
08.FLOW3
SP:01-99 | F:00-99
Internal Prog#8 Adjust SPEED and FLASH
09.FLOW4
SP:01-99 | F:00-99
Internal Prog#9 Adjust SPEED and FLASH
10.FLOW5
SP:01-99 | F:00-99
Internal Prog#10 Adjust SPEED and FLASH
11.FLOW6
SP:01-99 | F:00-99
Internal Prog#11 Adjust SPEED and FLASH
12.FLOW7
SP:01-99 | F:00-99
Internal Prog#12 Adjust SPEED and FLASH
Flip
OFF, ON
Set starting LED, see FLIP Section for more info.
Macros
00-63
Select Color Macro Value
LCD.Set
Backligh
02~60m 05m
LCD Backlight Shut Off Time
Key Lock
ON / ON1, OFF
Control Front Panel Buttons Key Lock
DisFlash
ON / OFF
Display flashes when NO DMX
DFSET
ON / OFF
Restore Factory Settings
TEMP
Fahren / Celsius
Temperature Switch Between F˚/ C˚
Info
TimeInfo
TimerPIN
PIN= 066
Enter PIN to Access Clear Last/Clear Total Menus
Current
XXXX (Hours)
Fixture Run Time From Power ON
TotalTim
XXXX (Hours)
Fixture Total Run Time
Last Clea
XXXX (Hours)
Clear Fixture Last Run Time
TempInfo
xxx°F
XXX F° / C°
Displays Temperature in Fixture Head
ModelInf
ELATION
Display Model Name
ErrorInf
Error Record 1 ~ Error Record 10
Display 10 Recent Error Messages
Software
1U ≥V101
2U ≥V101
Software Versions
Test
Reset. M
ZOOM
Reset of Zoom Motor
Calibrate
Password
Password= 050
Calibration of LEDS (RGBW) and Zoom Motor
Secondary
SECONDARY
SECONDARY Mode
Manual
Manual
ZOOM
000 - 255
Set Manual Zoom DMX Value
Dimmer
000 - 255
Set Manual Master Dimmer DMX Value
RED
000 - 255
Set Manual RED DMX Value
GREEN
000 - 255
Set Manual GREEN DMX Value
BLUE
000 - 255
Set Manual BLUE DMX Value
WHITE
000 - 255
Set Manual WHITE DMX Value
Strobe
000 - 255
Set Manual STROBE DMX Value
