18 VOLT Q5™ User Manual ver 1
FIXTURE MENU
ON-BOARD SYSTEM MENU
The VOLT Q5™ comes with an easy to navigate system menu. The next sections will
cover how to access each menu function.
LCD MENU CONTROL PANEL
The control panel located on the front of the fixture allows you to access the main
menu and make all necessary adjustments to the VOLT Q5™. During normal
operation, pressing MODE/ESC button once will access the fixture’s main menu.
Once in the main menu you can navigate through the different functions and
access the sub-menus with the UP and DOWN, buttons. Once you reach a field that
requires adjusting, press the ENTER button to activate that field and use the UP and
DOWN buttons to adjust the field. Pressing the ENTER button once more will confirm
your setting. You may exit the main menu at any time without making any
adjustments by pressing the MODE/ESC button.
INFORMATION DISPLAYED DURING INITIAL POWER ON
When the fixture is initially powered ON, the display shows the following information:
Wait . . . .
DatCheck
VOLT Q5
Addr=xxx
