SOURCE
(6) x 20W RGBLA+ UV LEDs
30,000 Hour Average LED Life*
*May vary depending on several factors including but not
limited to: Environmental Conditions, Power/Voltage, Usage
Patterns (On-O Cycling), Control and Dimming.
PHOTOMETRIC DATA
Total Lumen Output:
5,020 (Integrating Sphere)
CRI- 90.9
TLCI- 80
No Lens
• Beam Angle: 20°
• Field Angle: 33°
Included Frost
• Beam Angle: 30°
• Field Angle: 60°
EFFECTS
Prebuilt & Custom Standalone Eect Sequences
Full Pixel Control
Electronic Dimmer and Strobe
Variable 16-bit Dimming Modes and Curves
COLOR
RGBLA+ UV Color Array
CMY Emulation
Variable CCT 2400K - 8500K
Virtual Gel Swatch Book
CONTROL / CONNECTIONS
13 DMX Channel Modes (1ch, 3ch, 6ch, 9ch, 14ch,
17ch, 17ch, 23ch, 23ch, 35ch, 47ch, 83ch, 36ch)
4 Button Control Panel, LED Display
Aria p51-x2 Wireless Device Management
IR Remote
NFC Conguration
RDM (Remote Device Management)
IP65 5pin XLR DMX In/Out
IP65 Locking Power Cable In/Out
SIZE / WEIGHT
Length: 19.7” (501mm)
Width: 5.1” (129mm)
Vertical Height: 8.9” (226mm)
Weight: 18.8 lbs / 8.55kg
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
110W Max Power Consumption
Power Thru Capacity: 10A (10 units @110V; 21
units @240V)
5°F to 113°F (-15°C to 45°C)
BTU/hr (+/- 10%) 375.1
BATTERY
Lithium Ion Rechargable
Battery Capacity: 10.2 Ah
Battery Voltage: 18.5
Charge Time: 3hr
Battery Life: >12hr
Battery Recharge Cycles: >300 to 80% Capacity
APPROVALS / RATINGS
CE | cETLus | IP65 | FCC | UKCA
SPECIFICATIONS
Specications and documentation subject to change without notice.
IP65
4010765
