49
CAUTION! THE USE OF PROTECTIVE GLOVES AND SAFETY GOGGLES IS
STRONGLY RECOMMENDED WHILE PERFORMING THE IP PRESSURE TEST!
AVOID PLACING YOUR FACE, EYES, HANDS, ETC IN PROXIMITY TO THE LENS
OF THE FIXTURE WHILE PERFORMING THE TEST!
IP PRESSURE TESTING PARAMETERS
Test Type Low Pressure Limit High Pressure Limit Detection Time
Pressure Test
2.901 psi
(20.0 KPa)
3.336 psi
(23.0 KPa)
15 sec
Vacuum Test N/A N/A N/A
IP TEST PARAMETERS
Following any repair or maintenance procedure that requires disassembly of the fixture, use
Elation’s IP Tester to confirm the IP integrity of the fixture. This fixture features two air
valves: one of the front of the unit beside the lens, as well as one on the rear panel beside
the control panel. Air valve locations are shown in the diagram below. Please contact Elation
Service for information regarding the Elation IP Tester, or visit the product information page
online at: https://www.elationlighting.com/ip-tester
DE-HUMIDIFICATION: IP65 xtures operating in high-humidity environments may experience
residual fogging or condensation. Such fogging will not aect the xture, and can be removed
using the following procedure: position the unit with the air valve pointing upwards, then open
the air valves and run the unit for 1-2 hours after reaching operating temperature. Then, while
the xture is still hot, re-install the air valve and allow the unit to cool down. Please note:
this procedure should be performed in a dry, climate-controlled environment. Avoid additional
fogging by drying the xture completely before placing into a road case.
Air Valve
