18
ACCESSORY INSTALLATION
L-TRACK MOUNTING
Alternately, this unit’s L-track mounting system allows the user to slide the mounting clamps
along the tracks and lock them down in the desired position. The L-tracks are located along
the long sides of the unit’s body, as well as on the underside where the mounting brackets
attach. Special L-track mounting clamps, which incorporate an L-track attachment rail in
place of a mounting bolt hole, are available in both regular and extended lengths. Similarly,
L-track adapters are also available which can be fitted to any standard mounting clamp.
To attach an L-track clamp or adapter, simply insert the attachment rail into the matching
track on the fixture, slide to its desired location, and tighten the fastener knob on the
attachment to secure in place.
L-track
Clamp
L-track
Top Mount
L-track
Bottom Mount L-tracks
(Brackets Removed)
