Vision Color 250™
©Elation Professional® 24 Vision Color 250™
Main Menu Functions
1. ADDRESS MENU
- AOO1 - A511 (Value) - This is where you set the fixtures DMX address.
Setting/Changing the DMX Address
After applying power to the VISION COLOR 250™ the LED will display the fixture’s
current DMX address immediately after the reset sequence. If the fixture is not
receiving a DMX signal the display will flash continuously. To set or adjust a DMX
address, please follow the procedure below:
1. Switch on the VISION COLOR 250™ and wait for the fixture reset process to
finished.
2. Press the Mode/Esc button to access the main menu. Toggle through the menu by
pressing the Up and Down buttons until the display shows A001. Tap the enter
button to make changes to the address, the current three digit address will
immediately begin to flash.
3. While the current three-digit address is flashing, use the Up and Down buttons to
select adjust the address. Lock your new address into the unit’s memory by
pressing the Enter button. After the new address has been successfully stored into
the fixture’s memory the LED will briefly readout PASS.
The DMX address is non-destructible and will remain in the fixture’s memory even when
power to the fixture has been switched off. Memory is backed-up and retained by an
internal power source with a five year shelf life.
2. TEST MENU
- T-01 - T -XX (Test) - T ests the functions of each channel. There are 7 DMX
channels, and all channels except channel 5 can be tested. To enter the test menu follow
the procedure below:
1. Access the main menu.
2. Tap the UP button until “TEST” is displayed, press ENTER.
3. The display will show T-01. You can now press the up button and test the different
