©Elation Professional® - www.elationlighting.com - TVL1000 II Instruction Manual Page 16
TVL1000 II Power Cord Daisy Chain
Powered via power outlet: With this feature you can connect the
xtures to one another using the IEC input and output sockets.
The quantity that can be connected is 5 xtures maximum. After
5 xtures you will need to use a new power outlet. They must be
the same xtures. DO NOT mix xtures.
Powered via battery power: With this feature you can connect
the xtures to one another using the IEC input and output sock-
ets. The quantity that can be connected is 5 xtures maximum.
After 5 xtures you will need to use a new power outlet. They
must be the same xtures. DO NOT mix xtures.
NOTE: Powered via battery does not mean that 5 xtures are
being powered by one battyer, each unit must have a battery
connected.
©Elation Professional® - www.elationlighting.com - TVL1000 II Instruction Manual Page 15
TVL1000 II DMX Modes
TVL1000 II Photometric Chart
WARM WHITE (3200K)
COOL WHITE (6500K)
FULL ON (4500-5000K)
111 FC / 1200 LUX
143 FC / 1540 LUX
204 FC / 2200 LUX
30° Beam Angle
LUX
x
0.0929 = FC
0 m
0 ft
1 m
3.3 ft
4 m
13.1 ft
3 m
9.8 ft
2 m
6.6 ft
5 m
16.4 ft
Ø 1.0 m / Ø 3.3 ft
Ø 1.6 m / Ø 5.2 ft
Ø 2.1 m / Ø 6.9 ft
Min Beam Diameter
30° Beam Angle Ø 2.6 m / Ø 8.5 ftØ 0.5 m / Ø 1.6 ft
32 FC / 340 LUX
39 FC / 420 LUX
56 FC / 600 LUX
15 FC / 160 LUX
19 FC / 200 LUX
25 FC / 270 LUX
9 FC / 95 LUX
11 FC / 116 LUX
15 FC / 160 LUX
6 FC / 66 LUX
10 FC / 110 LUX
8 FC / 85 LUX
