16 TVL CYC RGBW™ User Manual
SYSTEM MENU CHANGE WITH SOFTWARE UPDATE VERSION 1.4
See highlighted menu items below which have been updated with this software update.
Supports Software Versions: ≥1.4
Features subject to change without any prior written notice.
MAIN MENU
SUB MENU
OPTIONS / VALUES
(Default Settings in BOLD)
DESCRIPTION
DMX Functions
DMX Address
001 - 512
Set DMX Address Setting
Channel Mode
Mode1(4ch), Mode2(6ch), Mode3(7ch)
Mode4(8ch), Mode5(10ch), Mode6(14ch)
Select DMX Channel Mode
View DMX Value
1. Red
xxx
Displays Current Manual DMX Values
2. Red Fine
xxx
3. Green
xxx
4. Green Fine
xxx
5. Blue
xxx
6. Blue Fine
xxx
7. White
xxx
8. White Fine
xxx
9. Color-Macros
xxx
10. Strobe
xxx
11. Dimmer
xxx
12. Dimmer Fine
xxx
13. Color-Temp
xxx
14. Dimmer Mode
xxx
DMX Last State
Last State, Blackout
Dimmer Curve
Standard, Stage, TV, Architectural, Theatre
Set Dimming Curve
White
Balance
Red
125-255
Adjust White Balance Setting
Green
125-255
Blue
125-255
White
125-255
Display Setting
Invert Display
No, Yes
Flip LCD Control Display 180°
Backlight Auto Off
No, Yes
Set LCD Display Backlight
Contrast Ratio
15 (0 - 30)
Adjust LCD Control Display Contrast Level
Unit Temperature
0I
Select Temperature Mode
Frequency
900Hz, 1000, 1200, 1300, 1400, 1500, 2500,
40000, 50000, 100000, 150000, 200000, 250000
Set LED Refresh Rate
Gamma
NO, 2.0, 2.2, 2.4, 2.8
Set LED Gamma Brightness
Color Chase
Fast, Fade Set Color Chase Speed
Manual Control
Red
0 - 255
Control DMX Values Manually
Red Fine
0 - 255
Green
0 - 255
Green Fine
0 - 255
Blue
0 - 255
Blue Fine
0 - 255
White
0 - 255
White Fine
0 - 255
Color-Macros
0 - 255
Strobe
0 - 255
Dimmer
0 - 255
Dimmer Fine
0 - 255
Color-Temp
0 - 255
Dimmer Mode
0 - 255
Fixture
Information
Fixture use time
0 (hours)
Fixture Information
Led Temp
II
Firmware Version
≥ 1.4
Factory Setting
No, Yes Reset to factory default settings
