Setup Menu
In Create New Fixture menu, use Cursor UP/DOWN buttons or F5 fader to scroll to [ TOTAL
DMX CHANNEL]. Pressing right arrow Select button gives access to setting and pressing
left arrow button allows you to go back the previous menu.
Total channels occupied on dmx
esc
ok
FIXTURE NAME - [ ]1
This menu allows you to determine how many channels your new fixture uses. You are
empowered to set a You can adjust the value in the
bracket using the Cursor UP/DOWN buttons or F5 fader. The choice is confirmed by
pressing the right arrow Select button.
scope ranging between 1 and 36.
Total DMX Channel
In Create New Fixture menu, use Cursor UP/DOWN buttons or F5 fader to scroll to
[ LCD EFFECT LABEL].
LCD Effect Label
Select feature to configure for
esc
ok
FIXTURE NAME - [ ]TOTAL DMX CHANNEL
Select feature to configure for
esc
ok
FIXTURE NAME - [ ]LCD EFFECT LABEL
Enter number of lcd pages
esc
ok
FIXTURE NAME - [ ]1
The flashing character(s) in the bracket reminds you to make a setting for the number of
pages required to view the fixture's effect on the LCD. The scope ranges between 1 and
5. You can adjust the value using Cursor UP/DOWN buttons or F5 fader.
This menu allows you to give a definition list of the commands required by the new
fixture to be written on the LCD. Pressing right arrow Select button gives access to
setting and pressing left arrow button allows you to go back to previous menu. A
dialog box appears in the LCD.
8
