25 SATURA SPOT CMY PRO™ User Manual
ELATION© SATURA SPOT CMY PRO™
DMX Channel Values / Functions - (33 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of COLOR, GOBO, and PRISM effects depends on the orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
BASIC VALUE EXTEND
9 11 16
ROTATING GOBO WHEEL, CONTINOUS ROTATION
0-9 OPEN
10-19
Rotating GOBO 1
20-29 Rotating GOBO 2
30-39
Rotating GOBO 3
40-49 Rotating GOBO 4
50-59
Rotating GOBO 5
60-69 Rotating GOBO 6
70-89
GOBO 1 Shake SLOW to FAST
90-109 GOBO 2 Shake SLOW to FAST
110-129
GOBO 3 Shake SLOW to FAST
130-149 GOBO 4 Shake SLOW to FAST
150-169
GOBO 5 Shake SLOW to FAST
170-189 GOBO 6 Shake SLOW to FAST
190-255
*Clockwise GOBO Wheel Rotation from SLOW to FAST
10 12 17
ROTATING GOBO WHEEL, INDEX ROTATION
0-127
GOBO Indexing
128-193 *Clockwise GOBO Rotation from FAST TO SLOW
194-255
*Counterclockwise GOBO Rotation from SLOW to FAST
18
ROTATING GOBO WHEEL, FINE INDEX ROTATION
0-255
Gobo Rotation FINE Indexing
11 13 19
FIXED GOBO WHEEL
0-13
OPEN
14-27 GOBO 1
28-41
GOBO 2
42-55 GOBO 3
56-69
GOBO 4
70-83 GOBO 5
84-97
GOBO 6
98-111 GOBO 7
112-127
GOBO 1 Shake SLOW to FAST
128-143 GOBO 2 Shake SLOW to FAST
144-159
GOBO 3 Shake SLOW to FAST
160-175 GOBO 4 Shake SLOW to FAST
176-191
GOBO 5 Shake SLOW to FAST
192-207 GOBO 6 Shake SLOW to FAST
208-223
GOBO 7 Shake SLOW to FAST
224-255 GOBO Wheel Rotation from SLOW to FAST
