www.elationlighting.com
19 SATURA SPOT CMY PRO™ User Manual
EDIT PROGRAM – Record Controller
The fixture features an integrated DMX-recorder by which you can transmit the
programmed scenes from your DMX-controller to the moving head. Adjust the
desired scene numbers via the encoder (from – to). When you call up the scenes at
your controller, they will automatically be transmitted to the moving head.
EDIT PROGRAM – Record Controller – Working With Built In Programs
A Master unit can send up to 3 different data groups to the Slave units, i.e. a Master
unit can start 3 different Slave units, which run 3 different programs. The Master unit
sends the 3 program parts in a continuous loop.
The Slave unit receives data from the Master unit according to the group which the
Slave unit was assigned to. If e.g. a Slave unit is set to “Slave 1” in the menu “Set to
Slave”, the Master unit sends “Auto Program Part 1” to the Slave unit.
If set to “Slave 2”, the Slave unit receives “Auto Program Part 2”.
To start an Auto Program proceed as follows:
1. Slave Setting
R-;B;9J“Function Mode”.
R+H;IIENTER to confirm.
R-;B;9J“Set to Slave”.
R+H;II ENTER to confirm.
R-elect “Slave 1”, “Slave 2” or “Slave 3”.
R+H;IIENTER to confirm.
R+H;IIMODE/ESC in order to return to the main menu.
