17 SATURA SPOT CMY PRO™ User Manual
PERSONALITY – Service Setting - Password
Display the fixture timer password. (050)
NOTE: The Service Password MUST be entered in order to access the following menus:
RDM PID, Ethernet IP, Ethernet IP Mask, and Clear Rst Info.
PERSONALITY – Service Setting - RDM PID
Select various submenus via RDM.
RDM stands for "Remote Device Management", which provides the ability to control
the device remotely while connected to a DMX-bus. ANSI E1.20-2006 by ESTA
specifies the RDM standard as an extension of the DMX512 protocol. Manual settings
like adjusting the DMX starting address are no longer needed. This is especially useful
when the device is installed in a remote area.
RDM ready and conventional DMX devices can be operated in one DMX line. The
RDM protocol sends its own packages in the DMX512 data feed and does not
influence conventional devices. If DMX splitters are used and RDM control is to be
used, these splitters must support RDM. The number and type of RDM parameters
depend on the RDM controller being used.
PERSONALITY - Display Setting – Key Lock
When ON, Control Panel buttons lock automatically after exiting main menu for 15
seconds. To unlock, keep MODE/ESC button pressed for 3 seconds.
EFFECT ADJUST – Test Channel
Select and auto test each individual channel function independently from the DMX
control board.
EFFECT ADJUST – Manual Control
Select and manually test and fine adjust each individual channel function
Independently from DMX control board. This function will center PAN and TILT motors
and set dimmer to 100%. PAN and TILT functions will still operate if the fixture needs to
be positioned to a flat clear surface. With the individual functions, you can focus the
light on a flat surface (wall) and perform fine adjustments.
