16
IP TEST PARAMETERS
Following any repair or maintenance procedure that requires disassembly of the fixture, use Elation’s
IP Tester to confirm the IP integrity of the fixture. Please contact Elation Service for information
regarding the Elation IP Tester, or visit the product information page online at: https://www.
elationlighting.com/ip-tester
CAUTION! THE USE OF PROTECTIVE GLOVES AND SAFETY GOGGLES IS STRONGLY
RECOMMENDED WHILE PERFORMING THE IP PRESSURE TEST! AVOID PLACING YOUR
FACE, EYES, HANDS, ETC IN PROXIMITY TO THE LENS OF THE FIXTURE WHILE
PERFORMING THE TEST!
DE-HUMIDIFICATION: IP65 xtures operating in high-humidity environments may experience residual
fogging or condensation. Such fogging will not aect the xture, and can be removed using the following
procedure: position the unit with the air valve pointing upwards, then open the air valve and run the
unit for 1-2 hours after reaching operating temperature. Then, while the xture is still hot, re-install
the air valve and allow the unit to cool down. Please note: this procedure should be performed in a
dry, climate-controlled environment. Avoid additional fogging by drying the xture completely before
placing into a road case.
Valves
IP PRESSURE TESTING PARAMETERS
Test Type Low Pressure Limit High Pressure Limit Hold Time
Vacuum Test -4.35psi (-30.00 KPa) -5.08 psi (-35.00 KPa) 10s
Pressure Test 3.62 psi (25.00 KPa) 4.35 psi (30.00 KPa) 10s
FIXTURE DISASSEMBLY
The following points should be observed after performing any maintenance procedure that
requires disassembly of the unit:
• After the unit has been reassembled, open the valve and allow the unit to run for
approximately 2 hours in order to dry out any moisture that has been trapped inside the
xture. The process should continue until indicated humidity drops below 15% for the head
and 30% for the base.
• Once this has been achieved, the light can be switched o, but the unit should remain
connected to power so that the cooling fan can cool down the unit. Please note that allowing
cool down time should ALWAYS be done after lamp operation.
• Some units may require partial disassembly in order to gain access to the valve. Please
contact Elation service for information regarding the location and access procedure for the
valve on your specic unit model.
