28RAYZOR Q7™ User Manual ver 1
ELATION© RAYZOR Q7™
DMX Channel Values / Functions (29 DMX Channels)
Specifications are subject to change without any prior written notice.
Mode/Channel
Value
Function
STAND
BASIC
EXTEND
10 8 6
SHUTTER, STROBE
0-31
Shutter CLOSED
32-63
No Function (Shutter OPEN)
64-95
Strobe Effect SLOW to FAST
96-127
No function (Shutter OPEN)
128-159
Pulse Effect In Sequences
160-191
No Function (Shutter OPEN)
192-223
Random Strobe Effect SLOW to FAST
224-255
No Function (Shutter Open)
11 9 7
DIMMER INTENSITY
0-255
Intensity 0 to 100%
12 10 8
COLOR MACRO
0-7
No Function
8-255
Color Macro Slow To Fast
13 11 9
COLOR PRESETS
0-10
NO Function
11-20
White 2700k
21-30
White 3200k
31-40
White 4300k
41-50
White 5600k
51-60
White 6500k
61-70
White 8000k
71-100
Blue [Group 1], Red [Groups 2,3,4]
101-130
Blue [Group 1], Green [Groups 2,3,4]
131-160
Green [Group 1], Red [Groups 2,3,4]
161-190
Red [Group 1], Blue [Groups 2,3,4]
191-220
Green [Group 1], Blue [Groups 2,3,4]
221-255
Red [Group 1], Green [Groups 2,3,4]
14 12 10
COLOR MODE
0-189
NO Function
190-254
Edit A New White Balance
255
Store A New White Balance
15 13 11
CHASE MACROS
0-10
LED OFF
11-40
Chase Macro 1
41-70
Chase Macro 2
71-100
Chase Macro 3
101-130
Chase Macro 4
131-160
Chase Macro 5
161-190
Chase Macro 6
191-220
Chase Macro 7
221-255
Chase Macro 8
16 14 12
CHASE SPEED
0-255
Fast To Slow
17 15 29
RESET INTERNAL PROGRAMS
0-79
Normal
80-84
All Motor Reset
85-87
NO Function
88-90
NO Function
91-93
Store White Balance Enabled
94-96
NO Function
97-99
NO Function
100-119
Internal Program 1 (Scene 1 - 8)
120-139
Internal Program 2 (Scene 9 - 16)
140-159
Internal Program 3 (Scene 17 - 24)
160-179
Internal Program 4 (Scene 25 - 32)
180-199
Internal Program 5 (Scene 33 - 40)
200-219
Internal Program 6 (Scene 41 - 48)
220-239
Internal Program 7 (Scene 49 - 56)
240-255
Music Control (Scene Of Program 1)
