www.elationlighting.com
27 RAYZOR Q12 ZOOM™ User Manual ver 1
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© RAYZOR Q12 ZOOM™
DMX Channel Values / Functions (28 DMX Channels)
Specifications are subject to change without any prior written notice.
*Position of LED GROUPS 2 and 3 depends on the orientation of the fixture head.
MODE / CHANNEL VALUE FUNCTION
BASIC STAND EXTEND
1 1 1
PAN MOVEMENT [8 BIT]
0-255 PAN Movement
2 2
PAN FINE MOVEMENT [16 BIT]
0-255 PAN Movement FINE Adjustment
2 3 3
TILT MOVEMENT [8 BIT]
0-255 TILT Movement
4 4
TILT MOVEMENT [16 BIT]
0-255 TILT Movement FINE Adjustment
3 5
RED LED - All Groups [1-3]
0-255 Red (0-Black - 255-100%)
4 6
GREEN LED - All Groups [1-3]
0-255 Green (0-Black - 255-100%)
5 7
BLUE LED - All Groups [1-3]
0-255 Blue (0-Black - 255-100%)
6 8
WHITE LED - All Groups [1-3]
0-255 White (0-Black - 255-100%)
7 9 5
SHUTTER, STROBE
0-31 LEDs OFF
32-63 LEDs ON
64-95 Strobe Effect SLOW to FAST
96-127 LEDs ON
128-159 Pulse Effect In Sequences SLOW to FAST
160-191 LEDs ON
192-223 Random Strobe Effect SLOW to FAST
224-255 LEDs ON
8 10 6
DIMMER INTENSITY
0-255 Dimmer Intensity 0 to 100%
9 11 7
DIMMING MODES
0-31 STANDARD
32-63 STAGE
64-95 TV
96-127 ARCHITECTURAL
128-159 THEATRE
160-255 Default to Fixutre Setting
10 12 8
ZOOM
0-255 ZOOM Adjustment from MIN to MAX
13 9
ZOOM FINE INDEXING
0-255 FINE ZOOM Adjustment
