IP66 RATED - OPS

The International Protection (IP) rating system is commonly expressed as “IP” (Ingress Protection)

followed by two numbers (i.e. IP66), where the numbers de󱁕ne the degree of protection. The 󱁕rst digit

(Foreign Bodies Protection) indicates the extent of protection against particles entering the 󱁕xture,

and the second digit (Water Protection) indicates the extent of protection against water entering the

󱁕xture. An IP66 rated lighting 󱁕xture is designed and tested to protect against the ingress of dust (6),

and high-pressure water jets from any direction (6).

The Atmospheric Corrosion rating indicates the degree of protection that a surface coating provides

against corrosion. It is commonly expressed as the letter C, followed by a number from 1 to 5 or the

letter X. This 󱁕xture is rated as CX (extreme), which means it is designed to provide protection in areas

of high salinity, industrial areas exposed to extreme humidity, aggressive atmospheres, or tropical

areas.

Maritime/Seaside Environment Installations: A maritime/seaside environment is adjacent to the sea

and caustic to electronics through exposure to atomized salt water and humidity, whereas a coastal

environment extends 5 miles inland.

A duty-cycle may also be needed when units are not in use. During times of high humidity and colder

temperatures, condensation may occur internally so the 󱁕xture may require a duty-cycle to bring it

up to running temperature, allowing any accumulation of moisture to be expelled via the vent valve.

Recommendations can change based on installation environmental circumstances.

NOTE: NOT ALL FEATURES LISTED ARE AVAILABLE ON ALL FIXTURES; THE FOLLOWING INSTRUCTIONS

MAY NOT APPLY. CONTACT SUPPORT FOR ADDITIONAL DETAILS.

Exterior Maintenance: Please note that the following are best practices, which are recommended

but not required. Inspect the exterior every 30-days. The unit must be powered o󱁔/disconnected. The

chassis should be inspected for any signs of contaminants. Inspect optics to determine if the lens is

obstructed, then clean optics and chassis accordingly. Based on initial 󱁕nding, schedule maintenance

accordingly, keeping in mind that exterior maintenance will be required. Even if the luminaires are NOT

in use, maintenance will still be needed given its location (exterior use). The use of a durable type of

wax on the chassis is recommended since it will help prevent contaminant build up. Inspect both power

and data lines for any signs of contaminants or corrosion. Periodically reapplying di-electric grease,

especially in coastal environments. If any signs of corrosion/contaminants are present, clean thoroughly,

and/or replace connectors, then reapply di-electric grease. Typically, this should be done annually, or

any time an opportunity presents itself. As a preventive measure, annual replacement of both vent

valves is recommended. The vent valve membrane can become contaminated and/or clogged causing

improper venting of humidity within the luminaire. Inspect all mounting hardware as a precaution.

Interior Maintenance: Inspect the interior every 30-days. The unit must be powered o󱁔/disconnected.

• Inspect zoom/focus mechanism, clean optics, lubricate linear bearings (Krytox oil) as needed, inspect

belts for wear

• Inspect all rotating e󱁔ect wheels, manually rotate them, note any resistance

• Inspect all remaining rotating belts for any wear

• Inspect all fans, clean as needed, check rotation, check connections

• Inspect CMY module, manually move 󱁖ags and check for signs of resistance, and if needed, clean

guide rods 󱁕rst, then reapply a thin layer of grease (moly lube)

• Clean interior with low-volume compressed air, then clean optics prior to reassembly of head covers

Although the base has limited moving parts, the pan belt should also be inspected for wear. Remember

to always perform an IP test anytime a cover is removed.

There is no speci󱁕c time frame regarding the routine replacement of parts such as belts/stepper motors,

PCBs, or LEDs. These items should only be replaced on an as needed bases, except for cooling fans, which

should be replaced once the luminaries reach 10,000-hours. This is a prophylactic measure intended

to keep the unit running as cool as possible, insuring proper function of all internal components. A

complete service breakdown is available, please contact service@elationlighting.com for any needed

parts or manuals.
