Je bekijkt pagina 41 van 59
41
DMX CHANNEL FUNCTIONS AND VALUES
DMX Channel Values / Functions (28 DMX Channels)
Supports Software Versions: ≥ 1.3.1
Features subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC STAND EXTEND
1 1 1
PAN MOVEMENT
0-255 PAN Movement
2 2
PAN FINE MOVEMENT [16 BIT]
0-255 Fine Control of PAN Movement
2 3 3
TILT MOVEMENT
0-255 TILT Movement
4 4
TILT MOVEMENT [16 BIT]
0-255 Fine Control of TILT Movement
3 5 5
CYAN COLOR
0-255 0-WHITE ~ 255-100% CYAN
6
CYAN COLOR FINE [16 BIT]
0-255 CYAN FINE Adjustment
4 6 7
MAGENTA COLOR
0-255 0-WHITE ~ 255-100% MAGENTA
8
MAGENTA COLOR FINE [16 BIT]
0-255 MAGENTA FINE Adjustment
5 7 9
YELLOW COLOR
0-255 0-WHITE ~ 255-100% YELLOW
10
YELLOW COLOR FINE [16 BIT]
0-255 YELLOW FINE Adjustment
6 8 11
COLOR WHEEL
0-10 OPEN / WHITE
11-19 RED
20-28 BLUE
29-37 GREEN
38-46 YELLOW
47-55 PINK
56-64 ORANGE
65-73 AQUA
74-82 LIGHT PINK
83-91 CYAN
92-100 MAGENTA
101-109 CTB
110-118 CTO
119-127 UV
128-189 *Clockwise COLOR Rotation from FAST to SLOW
190-193 NO Rotation
194-255 *Counterclockwise COLOR Rotation from SLOW to FAST
12
COLOR WHEEL FINE ADJUSTMENT [16 BIT]
0-255 FINE Adjustment of Color Wheel to Any Position
