32
SYSTEM MENU - Supports Software Versions: ≥ 1.3.1
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MAIN MENU SUB MENU OPTIONS / VALUES (Default Settings in BOLD) DESCRIPTION
FUNCTION
Set Dmx Address A001~AXXX DMX Address Setting
Dmx Value ALL…… DMX Value Display
Secondary Mode Secondary1, Secondary2, Secondary3 Secondary Setting
Auto Program Primary / Alone Auto Program
INFORMATION
Time Information
Current Time XXXX (Hours) Fixture Run Time From Power ON
Total Run Time XXXX (Hours) Fixture Total Run Time
Last Run Time XXXX (Hours) Fixture Last Run Time
Lamp Hours XXXX (Hours) Lamp Running Time
Lamp Off Time XXXX (Hours) Lamp Off Time
LastRun Password Password=038 (PSWD Required)
Clear Last Run ON / OFF Clear Fixture Last Run Time
LampTime Password Password=038 (PSWD Required)
Clean Lamp Time ON / OFF Clear Lamp Last Run Time
Temperature Info
Head Temperature XXX C° / F ° Temperature in Fixture Head
Base Temperature XXX C° / F ° Temperature in Fixture Base
Ethernet IP XXX . XXX . XXX . XXX XXX . XXX . XXX . XXX Displays Fixture Ethernet Address
Fan Info 1U_FAN1 - 6U_FAN2 RPM Speeds of Head/Base Fans
Encode Info PAN ENCODE:, TILT ENCODE:...
Software Version 1U01 - 6U01 ≥V1.3.1 Software Version
Error Info Error Record 1 ~ Error Record 10 Fixture Last 10 Error Codes
LAMP
CONTROL
Lamp ON/OFF ON/OFF Lamp ON/OFF
Automatic ON ON/OFF Lamp ON/OFF when Power ON
Lamp ON via DMX ON/OFF Lamp ON via DMX
Lamp OFF via DMX ON/OFF Lamp OFF via DMX
Max ON at Temp 20~79°C (45°C) / 68 ~ 174°F (113°F) Lamp Restart at Temp
Lamp OFF Temp 80~139°C (130°C) / 176 ~ 282°F (266°F) Lamp OFF at Temp
PERSONALITY
Status Settings
Address via DMX ON/OFF Address Via DMX
No DMX Status Close / Hold / Auto Fixture State When NO DMX Signal
Pan Reverse ON/OFF Pan Reverse Movement
Tilt Reverse ON/OFF Tilt Reverse Movement
Pan Degree 630/540 Pan Degree Select
Feedback ON/OFF Movement Feedback
Hibernation OFF, 01M~99M, 15M Stand By Mode
Service Setting
Password Password=050 Service Password
RDM PID 22A6xxxxxxxx RDM PID Code (PSWD Required)
Ethernet IP XXX.XXX.XXX.XXX Enter Fixture IP Address
Ether Mask IP XXX.XXX.XXX.XXX Enter Fixture Subnet Mask
Clear Err. Info ON/OFF Clear Error Info (PSWD Required)
DFLT Pow. LampOn ON/OFF Set Default Lamp Power State to ON
Display Setting
Shutoff Time 02~60m 05m Display Shut Off Time
Display Reverse AUTO/ON/OFF Display Reverse 180º
Key Lock ON/OFF Control Panel Lock Out
Temperature C/F
Celsius/Fahrenheit
Temperature Switch Between C˚/ F˚
Initial Status CONTROL =XXX Initial Effect Position
Select Signal
DMX ONLY Control via DMX only
DMX & E-FLY Control via DMX and E-FLY
E-FLY & OUT Control via E-FLY and sends DMX Out
Art-Net on IP2 Control via Ethernet 002 IP Address
Art-Net on IP10 Control via Ethernet 010 IP Address
sACN Control via sACN Protocol
Set Universe 000 - 255 Set ArtNet Universe
Set E-FLY Chn 00 - 15 Set E-FLY Wireless Channel
Reset Default ON/OFF Password=011 Restore Factory Settings (PSWD Required)
