LAMP INSTALLATION
LAMP REPLACEMENT
Please note that due to the nature of the Philips™ Platinum 14R
Lamp and the optical path of the fixture, the lamp MUST BE replaced
at 1,500 hours.
Use only Genuine Original Philips Platinum 14R Lamps. Other brand
lamps may cause damage and void warranty!
INSTALLING OR REPLACING THE LAMP
To ensure a proper/safe lamp change, carefully read all the following instructions.
LAMP PROTECTION CIRCUITRY
Because of the nature of the extreme heat associated with the Philips Platinum 14 R lamp and the unique IP65
rated sealed optical system, it is IMPERATIVE that the lamp be replaced at 1,500 Hours or sooner. This is
done to protect the internal sealed optical system as well as prevent accidental lamp explosion, which could
lead to hot glass particles falling from the fixture.
FAILURE TO CHANGE THE LAMP WITHIN 300 HOURS of the 1,500 HOUR RATED LIFE, WILL CAUSE THE
FIXTURE TO AUTOMATICALLY SHUT DOWN!
At 1,500 Hours the LCD control display will begin to flash, “Replace The Lamp” and the lamp will flicker for the
first five minutes of operation. At this point the lamp has reached the maximum rated life and should be
replaced immediately. After the lamp has flickered for about five minutes it should strike normally allowing the
fixture to be used temporarily until a replacement lamp can be installed. The fixture will continue to operate for
an additional 300 hours, however the “Replace the Lamp” warning will continue to flash in the display. Keep
in mind that the flicker protection circuitry will only work for about 300 Hours (lamp clock life of 1,500-1,800
Hours).
After 1,800 Hours the fixture will no longer respond to DMX commands and immediately enter a hibernation
mode that will electronically discontinue all fixture functionality with the exception of a few menu commands.
The fixture will continue to enter hibernation mode until the lamp is replaced and the lamp clock has been
reset. To replace the lamp follow the safety guidelines and procedures listed on the next page.
