Power Wash 250™
©Elation Professionals® Los Angeles, Ca. 90058 - www.ElationLighting.com - Page 36
5 Technical Specification
Power supply
Power consumption 500 Watt (blind current compensated)
EU- model AC 230V / 50 Hz~
Fuse protection T3.15A, 250V, 5x20 mm (fine-wire fuse)
US-model AC 115V / 60 Hz~
Fuse protection T6.3A, 115V, 5x20 mm (fine-wire fuse)
Lamp
Type 1 MSD 230V/250W, socket GY-9.5
Type 2 MSD 230V/200W, socket GY-9.5
Optical system
Aluminum reflector
Fresnel lens 150mm
Color
9 dichroic filter plus white 1x CTC 5600k, 1x CTC 3300k
Beam shape
Continuously Beam shape
Frost filter
Mechanically adjustable Beam angel 8˚-22°
Shutter / Strobe / Dimmer
Strobe effect, variable in speed 1 – 10 flashes per second
Continuously mechanical dimmer 0 - 100%
Controlling
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1.
The DMX addressing starts at the DMX- address [001].
Pan / Tilt
Pan- Movement 530° in max. 2,65 seconds, 16 Bit resolution
Tilt- Movement 280° in max. 1,68 seconds, 16 Bit resolution
Weights and measures
Width of the base 380 mm
Length of the base 380 mm
Height (head vertical) 500 mm
Weight (net) 22,2 kg
Weight (gross) 24,6 kg
Please Note: Specifications and improvements in the design of this unit and this
manual are subject to change without any prior written notice.
