Power Wash 250™
©Elation Professionals® Los Angeles, Ca. 90058 - www.ElationLighting.com - Page 31
Attention:
Be sure the lamp is securely seated in the lamp socket. Also pay close
attention to the lamp orientation, optimum distance between the lamp and
the lens should range between 1.0 - 1.5 mm. Failure to comply with this
warning may cause excessive heat build-up that may cause the internal
lens to crack.
Lamp Optimization
The lamp orientation and optimization must be adjusted after every lamp change. This
procedure centers the lamp in the reflector. Proper optimization will increase lamp life
and ensure a bright crisp output. Improper optimization may add a yellow tint to the
lamp output and reduce intensity. The minimum deviation amount is 1.0mm. Running
the fixture within a lower deviation can cause damage to the lamp and/or lens.
The POWER WASH 250™ lamp holder is aligned at the factory. However, due to slight
imperfections in all lamps, fine adjustments may improve light performance. Please
follow this procedure:
1. Strike the lamp (for example in the
LAMP menu) and wait a while until full
intensity of the lamp.
2. Using either a DMX controller or the control panel on the unit, strike the lamp
and focus the light on a flat surface.(beam open, white, no gobo, no effects).
3. Center the hot-spot (the brightes t part of the beam) using the 3 adjustment
screws. Turn one screw at a time to drag the hot-spot diagonally across the
projected image. If you cannot detect a hot-spot, adjust the lamp until the light
is even.
4. To reduce a hot-spot, pull the lamp in by turning all three screws clockwise 1/4-
turn at a time until the light is evenly distributed.
