Power Spot 250™
©Elation Professionals® Los Angeles, Ca. - wwww.ElationLighting.com - Page 35
6.3.1 Strike the lamp (through the internal menu functions or with a DMX controller) and
wait a while until full intensity of the lamp.
6.3.2 Using either a DMX controller or the control panel on the unit, strike the lamp and
focus the light on a flat surface.(beam open, white, no gobo, no effects).
6.3.3 Center the hot-spot (the brightest part of the beam) using the 3 adjustment
screws. Turn one screw at a time to drag the hot-spot diagonally across the
projected image. If you cannot detect a hot-spot, adjust the lamp until the light is
even.
6.3.4 To reduce a hot-spot, pull the lamp in by turning all three screws clockwise 1/4-
turn at a time until the light is evenly distributed.
6.3.5 If the light is brighter around the edge than it is in the center, or if light output is
low, the lamp is too far back in the reflector. “Push” the lamp out by turning the
screws
NOTICE: Be sure the minimum distance between the lamp and lens is at least 1.0mm. If
the distance between the lamp and lens is less then 1.0mm, the lens may shatter due to
excessive heat built-up.
