Power Spot 250™
©Elation Professionals® Los Angeles, Ca. - wwww.ElationLighting.com - Page 33
fastening screw
lamp
cover plate
lamp
6. Lamp Replacement
For a proper and safe lamp change, please read this chapter carefully and follow all
instructions.
6.1 Safety Regulations
• Pull out the main plug!
• Wait min. 20 minutes after the last operation to cool down the fixture.
• Don’t touch the bulb of the lamp with bare fingers (this can cause damages.
• Before you put the POWER SPOT 250™ into operation close the casing, otherwise
your retina can be hurt!
6.2 Lamp Change
6.2.1 Be sure the unit is disconnected from it’s
main power supply.
6.2.2 Remove the upper shell of the protective
cover by removing the 4 retaining Phillips
screws, 2 located on the front and 2 located
on the rear of the head.
6.2.3 Once the outer cover has been removed,
expose the lamp by removing the lamp
cover plate. Remove the lamp cover plate
by unscrewing 3 thumb screws. Refer to
the illustration on the left.
6.2.4 Gently remove the old lamp from it’s socket.
If the old lamp has exploded be sure to
remove all of the old lamp fragments to
prevent damage to the internal
components.
6.2.5 Replace the lamp with an approved replacement type. Be sure to follow all the
lamp handleing procedures included with your new lamp. Never handle the new
lamp with your bare hands, the oils from your skin may damage the lamp. Always
replace with the lamp with a lamp that meets the orginal lamp specification, failure
to do so may damage the unit and will void your manufactures warranty.
6.2.6 Before reassembing the unit, be sure to adjust the lamp distance from the main
