Platinum Spot LED Pro™

©Elation Professional, Los Angeles Ca. 12 www.ElationLighting.com

12. Enter Button – The enter button is used to enter in to a certain menu function or to lock

a function into memory.

13. Carrying Handle – Please use this intergraded handled to move the fixture form

location to location. Never carry the fixture by the head.

12. Lamp Access Panel – This panel provides access to the lamp and lamp socket

assembly. Always allow ample time for the lamp to cool before attempting access to the

lamp and lamp socket.

14. 5-PIN DMX Input Jack – This jack accepts an incoming DMX signal via a male, 5-pin

XLR jack.

15. 5-Pin DMX Output Jack – This jack is used to send an incoming DMX signal to the

next fixture in the DMX chain via a female, 3-pin XLR jack.

16. 3-PIN DMX Input Jack – This jack accepts an incoming DMX signal via a male, 3-pin

XLR jack.

17. 3-Pin DMX Output Jack – This jack is used to send an incoming DMX signal to the

next fixture in the DMX chain via a female, 3-pin XLR jack.

18. Power Switch – This comes with both a main power and DC power switch. This switch

controls main bus power to the unit.

19. Fuse Holder Assembly – This assembly houses the 4amp GMA safety fuse. Always

replace the fuse with an exact match unless otherwise specified by an authorized

Elation Service Technician. Using a fuse other than that specified could seriously

damage the unit and will void your manufactures warranty.

20. Power Cord – Plug into an appropriate power outlet to provide main power to the

fixture.
