www.elationlighting.com
25 PLATINUM SPOT 35 PRO™ User Manual Version 1
EFFECT ADJUST – Test Channel
Select and auto test each individual channel function independently from the DMX
control board.
EFFECT ADJUST – Manual Control
Select and manually test and fine adjust each individual channel function
Independently from DMX control board. This function will center PAN and TILT motors
and set dimmer to 100%. PAN and TILT functions will still operate if the fixture needs to
be positioned to a flat clear surface. With the individual functions, you can focus the
light on a flat surface (wall) and perform fine adjustments.
EFFECT ADJUST – Calibration
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION.
This function allows small adjustments to be made to the effect wheels (Color, Gobo,
Shutter, etc.) to compensate for ware or in the event a sensor has been knocked
slightly out of place. Because improper use of this function can result in undesired
operation this function has been password protected. The password is 050 and must
be entered each time the calibration menu function is entered. Because calibration
is an extremely delicate procedure, instructions on performing this action are left out
of this manual. For a first time calibrator, please contact our customer support team
for step-by-step instructions.
USER MODE SET – User Mode
Select operating mode, which includes DMX Channel and User defined modes.
USER MODE SET – Edit User Mode
Create user defined channel orders allowing the fixture to match the channel order
of other fixtures on the market for easier operation. A total of three user modes may
be configured: User Mode A, User Mode B, and User Mode C.
EDIT PROGRAM – Select Program
Select one of the (10) user defined internal Auto Programs.
EDIT PROGRAM – Edit Program
Edit any of the (10) user defined internal Auto Programs.
EDIT PROGRAM – Edit Scenes
Edit any of the scenes of the internal Auto Programs.
