11
INSTALLATION GUIDELINES
OMEGA BRACKET INSTALLATION
Insert the Omega Bracket into the matching holes on the bottom of the fixture. Secure the
Omega Bracket to the fixture by turning each quick-lock fastener ¼ turn clockwise; making
sure the fastener is completely locked.
CLAMP INSTALLATION
When mounting fixture to truss, be sure to secure an appropriately rated professional grade
rigging clamp to the included Omega Bracket using an M10 screw fitted through the
center hole of the Omega Bracket. The fixture provides a built-in rigging point for a
SAFETY CABLE. Be sure to only use the designated rigging point for the safety cable and
never secure a safety cable to a carrying handle.
RIGGING
Overhead rigging requires extensive experience, including amongst others calculating
working load limits, installation material being used, and periodic safety inspection of all
installation material and the fixture. If you lack these qualifications, do not attempt the
installation yourself. Improper installation can result in bodily injury
ALWAYS ATTACH AN APPROPRIATELY RATED SAFETY CABLE (NOT
INCLUDED) THAT MEETS ALL LOCAL, NATIONAL, AND COUNTRY CODES
AND REGULATIONS WHENEVER INSTALLING FIXTURE IN A SUSPENDED
ENVIRONMENT!
