ELATION PLATINUM BEAM 5R EXTREME

S Y S T E M M E N U

Specifications and features are subject to change without any prior written notice.

MAIN MENU

SUB MENU

OPTIONS / VALUES (Default Settings in BOLD)

DESCRIPTION

FUNCTION

Set DMX Address

A001~AXXX

DMX Address Setting

DMX Value

ALL……

DMX Value Display

Secondary Mode Secondary1, Secondary2, Secondary3 Secondary Setting

Auto Program

Primary / Alone

Auto Program

Sound Control

Primary / Alone

Sound Control

INFORMATION

Time Information

Current Time

XXXX (Hours)

Fixture Run Time From Power ON

Total Run Time

XXXX (Hours)

Fixture Total Run Time

Last Run Time

XXXX (Hours)

Clear Fixture Last Run Time

Lamp Hours

XXXX (Hours)

Lamp Total Run Time

Lamp Off Time

XXXX (Minutes)

Lamp OFF Time

LastRun Password

Password=XXX

Password 038

Clean Last Run

ON / OFF

Reset Fixture Last Run Time

LampTime

Password

Password=XXX

Password 038

Clean Lamp Time

ON / OFF

Reset Lamp Run Time

Temperature Info

Head Temperature

XXX C° / F °

Temperature in Fixture Head

Software Version

V1.0.0...

Software Version

LAMP

CONTROL

Lamp ON or OFF

ON/OFF

Lamp ON/OFF

Automatic Lamp ON

ON/OFF

Lamp ON/OFF when Power ON

Lamp ON via DMX

ON/OFF

Lamp ON via DMX

Lamp OFF via DMX

ON/OFF

Lamp OFF via DMX

Max ON at Temp

20~79°C (45°C) / 68 ~ 174°F (113°F)

Lamp ON at Temp

Lamp OFF Temp

80~139°C (130°C) / 176 ~ 282°F (266°F)

Lamp OFF at Temp

PERSONALITY

Status Settings

Address via DMX

ON/OFF

Address Via DMX

No DMX Status

Close/Hold/Auto/Music

Auto Run If No DMX

Pan Reverse

ON/OFF

Pan Reverse Movement

Tilt Reverse

ON/OFF

Tilt Reverse Movement

Pan Degree

630/540/540-90 Offset

Pan Degree Select

Feedback

ON/OFF

Movement Feedback

Movement Speed

Speed 1 ~ 4

Movement Mode Select

Mic Sensitivity

0-99%

Sensitivity of Microphone

Hibernation

OFF, 01M~99M, 15M

Stand By Mode

Service Setting

Password

Password=XXX

Service Password 050

RDM PID

XXXXXX

RDM PID Code

Fans Control

Auto, High, Low

Fans Speed Select

Display Setting

Shutoff Time

02~60m 05m

Display Shut Off Time

Display Reverse

ON/OFF

Display Reverse 180º

Key Lock

ON/OFF

Key Lock

Temperature C/F

Celsius/Fahrenheit

Temperature Switch Between C˚/

F˚

Initial Status

PAN =XXX

Initial Effect Position

Wireless DMX

WDMX OFF

De-activate WDMX

Activate WDMX

Act & Data Out

Clean WDMX Memo

Reset Wireless DMX Mem

Reset Default

ON/OFF

Restore factory settings
