LAMP INSTALLATION

LAMP REPLACEMENT

Please note that due to the nature of the Philips™ Platinum 5R

Lamp and the optical path of the Elation PLATINUM BEAM 5R

EXTREME fixture, the lamp MUST BE replaced at 2,000 hours.

Use only Genuine Original Philips™ Platinum 5R Lamps. Other

brand lamps may cause damage and void warranty!

INSTALLING OR REPLACING THE LAMP

To ensure a proper/safe lamp change, carefully read all the following instructions.

LAMP PROTECTION CIRCUITRY

Because of the nature of the extreme heat associated with the Philips Platinum 5R lamp

and the tight nature of the internal optical system, it is IMPERATIVE that the lamp be

replaced every 2,000 Hours. This is done to protect the internal optical system as well as

prevent accidental lamp explosion, which could lead to hot glass particles falling from the

fixture.

FAILURE TO CHANGE THE LAMP WITHIN 300 HOUR of the 2,000 HOUR RATED LIFE,

WILL CAUSE THE FIXTURE TO AUTOMATICALLY SHUT DOWN!

At 2,000 Hours the LCD control display will begin to flash, “Replace The Lamp” and the

lamp will flicker for the first five minutes of operation. At this point the lamp has reached the

maximum rated life and should be replaced immediately. After the lamp has flickered for

about five minutes it should strike normally allowing the fixture to be used temporarily until

a replacement lamp can be installed. The fixture will continue to operate for an additional

300 hours, however the “Replace the Lamp” warning will continue to flash in the display.

Keep in mind that the flicker protection circuitry will only work for about 300 Hours (lamp

clock life of 2,000-2,300 Hours).

After 2,300 Hours the fixture will no longer respond to DMX commands and immediately

enter a hibernation mode that will electronically discontinue all fixture functionality with the

exception of a few menu commands. The fixture will continue to enter hibernation mode

until the lamp is replaced and the lamp clock has been reset. To replace the lamp follow the

safety guidelines and procedures listed on the next page.
