Je bekijkt pagina 28 van 38
www.elationlighting.com 28
Supports Software Versions: ≥ 2.1.0
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
9 27 83
DIMMER INTENSITY
0-255 Dimmer 0 to 100%
84
DIMMER INTENSITY FINE
0-255 Dimmer FINE Adjustment
10 28 85
DIMMER MODES
0-20 Standard
21-40
Stage
41-60 TV
61-80 Architectural
81-100 Theatre
101-255 Default to Setting on Fixture
11 29 86
MOTORIZED ZOOM
0-255 ZOOM Adjustment from SMALL to BIG
87
MOTORIZED ZOOM FINE
0-255
ZOOM FINE Adjustment
12 30 88
PATTERNS AND CHASE MACROS
0-14
NO FUNCTION (LEDs OFF)
15-30
Center Pixel
31-46 Inside Pixel Ring
47-62
Outside Pixel Ring
63-78 Center Pixel & Inside Pixel Ring
79-94 Inside & Outside Pixel Rings
95-110 All Pixels
111-126 Chase 1
127-142 Chase 2
143-158 Chase 3
159-174 Chase 4
175-190
Chase 5
191-206 Chase 6
207-222
Chase 7
223-238 Chase 8
239-255
Chase 9
13 31 89
CHASE SPEED
0-125 *Counterclockwise Chase Speed FAST to SLOW
126-130 STOP (Speed = 0)
131-255 *Clockwise Chase Speed SLOW to FAST
14 32 90
CHASE FADE
0-255 Chase Fade
15 33 91
COLOR MODE - WHITE BALANCE
0-189
NO FUNCTION
190-254 EDIT a New WHITE BALANCE Setting
255
SAVE New WHITE BALANCE Setting to Fixture(s)
*NOTE: DMX VALUE of 91-93 MUST FIRST BE SELECTED ON
CH17 (Basic), CH35 (Stand), or CH93 (Extend) TO ENABLE FEATURE.
16 34 92
PAN / TILT MOVEMENT SPEED
0-225 MAX to MIN Speed
226-235 Blackout by Movement
236-255 NO FUNCTION
NOTE
Colors must be selected for
PATTERNS AND CHASE
MACROS to function and
colors are determined by
the RGBW and/or COLOR
PRESETS values selected.
