Touch D21 once and then twice, Line 5 will change from red to green and blue. Now the unit has been at the
end of the whole setting circle. Touch D21 again, the setting will move back to the first item of touch-color
setting.
Background Color
LED Line LED Color Signification
Line 1 (D1~D5) green (default setting) background color (variable as per the mixing of the
red, green, and blue sections)
Line 2 (D6~D10) red ( 0% intensity) red section of background color (syncrhonizing with
Line 5 when it is red in color )
Line 3 (D11~D15) green green section ofbackgroundcolor(syncrhonizing
with Line 5 when it is green in color)
Line 4 (D16~D17) blue blue section of background color (syncrhonizing
with Line 5 when it is blue in color)
Line 5 (D21~D25) red (twinkling) the color section(red, green or blue) under setting
Touch D21 to enter background color setting. Please view the following table about the LED significations.
The maximum touch-delay time available is 530 sec. Please view the formula below to bring out the exact
touch-delay time:
LED amount of the same line & color its unit time value) time values of other LEDs Touch-delay Timex+ =
System Connection
It is required to make a proper system connection prior using this fixture, the following contents present you
the single module connection methods on next page.
~3~
