SPECIFICATIONS
SOURCE
High Eciency 900W 6,500K Variable CRI White LED
Engine
30,000 Hour Average LED Life*
*Test lab conditions. May vary depending on several
factors including but not limited to: Environmental
Conditions, Power/Voltage, Usage Patterns (On-O
Cycling), Control, and Dimming.
PHOTOMETRIC DATA
37200 Total Lumen Fixture Output @ CRI 80
TruTone variable CRI up to CRI 93
Prole Lens (standard)
Zoom Range 4.5° - 52°
Beam Angle 4° - 48.6°
Field Angle 4.4° - 52°
Cuto Angle 4.5° - 54.2°
PC Lens (optional)
Zoom Range 6° - 50°
Beam Angle 3.7° - 44.5°
Field Angle 5.8° - 50.2°
Cuto Angle 6.7° - 52.1°
Fresnel Lens (optional)
Zoom Range 9° - 55°
Beam Angle 4.5° - 46.8°
Field Angle 8.9° - 54°
Cuto Angle 13.4° - 60.4°
EFFECTS
Motorized Zoom
4 Full Blackout Framing Blades, +/-45° Index
+/-120° Framing Index
Full 360° Bi-Directional Animation Wheel
4-Facet Round and Linear Rotating Prisms
2 Variable Frost Filters (Light and Wash)
Motorized Iris with Variable Pulse Eects
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
DMX Controllable LED Refresh Rate
Pan Angle: 540°
Tilt Angle: 260°
COLOR
CMY Color Mixing
Linear CTO Color Correction
6 Dichroic Colors including UV Filter, Quad Color
TruTone variable CRI 70-93
GOBOS
2x 7 Rotating / Indexing Interchangeable Glass Gobos
CONTROL / CONNECTIONS
4 DMX Channel Modes
16-bit Pan, Tilt and Dimming Control
5 Fan modes for ultra quiet operation
DMX, RDM, Art-NET, sACN Protocol Support
(4) Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
NFC on bottom and front of xture base
Hibernation Mode (Power Save)
IP65 Locking 5pin XLR In/Out
IP65 Locking RJ45 Ethernet In/Out
IP65 Locking Power In
SIZE / WEIGHT
Length: 17.5 in (444mm)
Width: 12.4 in (315mm)
Height: 26.6 in (680 mm)
Weight: 70.5 lbs. (32 kg)
MOUNTING
2x 180mm Omega Bracket
2x M12 Screw Hole
Fixture can be mounted in any orientation
ELECTRICAL
AC 100-240V 50/60Hz
Max Power Consumption 1400W
-4°F to 113°F (-20°C to 45°C)
INCLUDED ITEMS
Omega Brackets (x2)
IP65 Rated Locking Power Cable
Stainless Steel Safety Wire
Foam Inlay
APPROVALS / RATINGS
CE | cETLus | FCC | UKCA | IP54
Specications and documentation subject to change without notice.
3104374
