ERROR CODES
Error Codes subject to change without notice
ERROR CODES DESCRIPTION
Pan Er Pan motor error
Tilt Er Tilt motor error
Cyan Color Er Cyan motor error
Magenta Color Er Magenta motor error
Yellow Color Er Yellow motor error
CTO Color Er CTO motor error
Gobo Wheel Er Gobo wheel motor error
Gobo Rot Er Gobo rotation motor error
Zoom Er Zoom motor error
Iris Er Iris motor error
Focus Er Focus motor error
Frost Er Frost motor error
When powered on, the unit will automatically enter a “Reset/Test” mode, which brings all the
internal motors to home position. If an internal problem is detected with one or more of the
motors, an error code will ash in the display in the form of “XX Er”, where XX represents an
error code. For example, when the display shows “Pan Er” it means there is some type of error
with the Pan motor. If there are multiple errors during the start-up process, they will all be
shown in the display. For example, if the xtures has errors with the pan, tilt, and cyan motors
all at the same time, you will see the error message “Pan Er”, “Tilt Er”, and “Cyan Color Er”
repeated 5 times.
If an error occurs during the initial start-up procedure, the xture will self-generate a second
reset signal and try to realign all the motors and correct the errors. If the error persists after
a second attempt, a third attempt will be made. If after a third attempt all the errors have not
been corrected, the xture will proceed according to the guidelines below:
• 3 or More Errors: The xture cannot function properly with three or more dierent types
of errors, and therefore the xture will place itself in a stand-by mode until repairs can be
made.
• Less Than 3 Errors: Most other functions will work properly. The xture will attempt to
operate normally until the errors can be corrected by a technician. The errors in question
will remain ashing in the display as a reminder of internal errors.
