LED Display On/Off:

To set the LED display to turn off after 10 seconds, press the MODE

button until DS-1 is displayed, press the UP button to display DS-2.

Now the display will disappear after 10s. Press any button to turn

the display on again. Be advised though that the display will turn off

automatically after 10 seconds.

To set the display press the MODE button until DS-X is displayed. “X”

represents the number displayed.

DS-1= LCD display on at all times.

DS-2= LCD display shuts off after 10 seconds.

Operating Modes:

• Sound-Active mode - The unit will react to sound. There are 5 different

sound active programs to choose from.

• Auto Mode - There are 4 built in programs to choose from. The speed

of these programs can be adjusted as well.

• DMX control mode - This function will allow you to control each

individual fixtures traits with a standard DMX 512 controller such as

as the Elation® Show Designer™.

Master-Slave Operation:

This function will allows you to link units together to run in a Master-

Slave mode. In Master-Slave operation one unit will act as the controlling

unit and the others will react to the controlling units built-in programs.

Any unit can act as a Master or as a Slave however, only one unit can be

programmed to act as the “Master.”

Master-Slave Connections and Settings:

1. Daisy chain your units via the XLR connector on the rear of the unit.

Use standard XLR microphone cables to link your units together.

Remember that the Male XLR connector is the input and the Female

XLR connector is the ouput. The first unit in the chain (master) will

use the female XLR connector only. The last unit in the chain will use

the male XLR connector only.

2. Set the “Master” unit to your desired mode or operation.

3. For the “Slave” unit(s), set the display to DMX address 1.

4. Connect the “Slave” unit or units and they will automatically start to

follow the “Master.”

Opti 30 UV Operating Instructions

Elation Professional - www.elationlighting.com - Opti 30 UV Instruction Manual Page 8Elation Professional - www.elationlighting.com - Opti 30 UV Instruction Manual Page 7

Sound Active Mode:

In this mode the Opti 30 UV will react to sound, and chase through the

different colors. There are 5 different sound active programs to choose

from.

1. Plug the fixture in and press the MODE button until “2-XX” is dis-

played. “XX” represents the current sound active program that is dis-

played.

2. There are 5 different sound active programs to choose from.

The programs are:

2-01 = Increase the intensity

2-02 = Decrease the intesity

2-03 = Increase and decrease the intensity

2-04 = Strobe

2-05 = Mixing

3. Use the UP and DOWN buttons to find your desired mode.

Auto Mode:

1. Plug the fixture in and press the MODE button until “3-XX” is dis-

played. “XX” represents the current program that is displayed.

2. There are 4 built in programs to choose from. The programs are:

3-01 = Increase the intensity

3-02 = Decrease the intesity

3-03 = Increase and decrease the intensity

3-04 = Strobe

3. Use the UP and DOWN buttons to find your desired program.

You can set your program speed by following the instructions below.

Auto Mode Speed Adjustment:

1. To adjust the speed of your Auto mode program press the MODE

button until “4-XX” is displayed.

2. Press the UP or DOWN buttons to make the adjustmetns. “4-00” is

the slowest speed, “4-20” the fastest speed.

Strobe Mode:

1. Plug the fixture in and press the MODE button until “5-XX” is dis-

played.

2. Press the UP or DOWN buttons to make the adjustmetns. “5-00” is

the slowest speed, “5-255” the fastest speed.

DMX Mode:

Operating through a DMX controller gives the user the freedom to create

Opti 30 UV Operating Instructions
