3
1. Overview
THE ENCODER
THE RIGHT BUTTON
The encoder can be turned with or without simultaneously pressing a
button; the functions will be different in the various menus.
Programming is only possible by pressing a button and turning the
encoder at the same time.
4
5
MDP-1219 Instructions page 5
ANALOG IN
DC 0V~10V
LINK OUT
23-001-0841
MIDI
LINK IN
MIDI
LINK THRU
DMX IN
2 1
3
DMX OUT
2
3
1
1=Ground
2=Data-
3=Data+
1=Ground
2=Data-
3=Data+
3
4
5
6
2
1
1. Overview
3
MDP-1219 Instructions page 6
LCD DISPLAY
Used to display various menus and submenus.
THE LEFT BUTTON
THE MIDDLE BUTTON
The three "basic menus" can be selected one after the other by this
middle button.
1
2
3
1.1 Front View 1.2 Rear View
THE CHANNEL DIMMER MODULE (x12)
The channel dimmer module is incorporated with a 10A circuit breaker
and SCRs with 1000A peak current capacity. The removable, plug &
play module enables easy and flexible setup of 12 channel module.
6
