63
MENU MENU
DMX FAIL OFF
DMX MODE BLOCK
MIDI/DMX DMX
MIDI CHANNEL 01
---------------------------------
PHASE CORR. YES
USER MODE SUPER
MASTER/SLAVE MASTER
UNIT No 01
CURVE USER1 EDIT
CURVE USER2 EDIT
---------------------------------
CLEAR CURVES CLEAR
DELETE ALL DELETE
Ver:1.0
OFF
Setup Menu
1 2
3
4
<<
<<
MDP-1219 Instructions page 19
1 Once press the Menu button, this menu switches back to the Top Menu.
2 Tap the right button and turn the encoder simultaneously, the
parameters on the right of the item selected alter continually. A big
character at the right corner displays the corresponding item selected.
3 Turn the encoder without tapping any button, the cursor moves up and
down, selecting the desired item to set the parameters.
4 When USER CURVE is selected, press this button, you can enter
Curve edit menu.
2.4.1 DMX Fail
Here the reaction to failing DMX signal can be programmed
- HOLD : holds the last received DMX signal until a new DMX signal
reaches the dimmer.
The analogue input(0~10V) will be switched off,
- OFF : holds the last received DMX signal for 1 second and then
switches off.
when a valid DMX signal is received.
- CHA 1s : starts the internal chase after waiting for 1 second.
- M1 1s : calls the internal memory No.1 after waiting for 1 second.
- M2 1s : calls the internal memory No.2 after waiting for 1 second.
Note : Calling of other memories is the same as above.
6
3
OPERATION
- CHA 9s : starts the internal chase after waiting for 9 seconds.
MDP-1219 Instructions page 20
2. Operating Guide 2. Operating Guide
2.4 Setup Menu 2.4 Setup Menu
OPERATION
- M1 9s : calls the internal memory No.1 after waiting for 9 seconds.
- M2 9s : calls the internal memory No.2 after waiting for 9 seconds.
Note: That other memories are called is similar to that described above.
The actual status will be displayed in the Top Menu (message : " NO DMX")
CHASE
