63
MDP-1219 Instructions page 13
63
MDP-1219 Instructions page 14
2. Operating Guide 2. Operating Guide
2.1 Top Menu
8 A short touch sets selected channel(1) to predefined value(e.g.20%).
Tapping again will switch it off. While holding down the right button, turn
the encoder(Data Wheel),this value will be stored after switchover.
9 Temporarily turn the encoder to select one of 12 channels.
10 If DMX signal is received, both the channel in which DMX data alters
and the value after being changed will be indicated. If no DMX signal
received,"NO DMX" is displayed. When selected, MIDI is indicated.
11 Temporarily adjusts internal patterns.
ADDITION:
1. Hold down the right button,"CLEAR ALL" appears at the left corner of
the LCD display. Once you tap the right button, all temporary settings for
each channel are to be deleted.
2. Particular attentions shall be taken to that:
The settings of the channels will not be stored permanently and not be
recalled after power off. Please use the internal Memories .
2.2 Channel Menu
NO
DMX PRE LTM LCCUR
1
2
3
4
5
6
7
8
9
10
11
12
1
-
-
Cu1
Cu2
SW
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
30
100
100
100
100
100
100
100
100
100
100
100
2
3
4
5
6
7
8
9
10
11
12
CHA
1
15
30%
MENU MENU
1 2
3
4
5
6
10
11 12
13
14
16
15
7
8
9
Channel Menu
<<
<<
1 The shade is the cursor.
2 Preheat set to 15%.
3 Channel 1 limited to 30%. All others have no limits (100%).
4 Selected Channel (Encoder)
5 DMX address for channel 4
6 Control curve "Curve 1"
OPERATION
7 Control curve "Curve 2"
8 Switch status
