©Elation Professional® 26 impression™
10. DMX CHANNEL TRAITS:
The chart below details the channel layout for 14 DMX channels (default).
CHANNEL 1: Pan Movement (max. 630° or 540˚ User Selectable)
CHANNEL 2: 16bit Pan Movement (pan fine)
CHANNEL 3: Tilt Movement (max. 265°)
CHANNEL 4: 16bit Tilt Movement (tilt fine)
CHANNEL 5: Color (Fixed)
CHANNEL 6: Red
CHANNEL 7: Green
CHANNEL 8: Blue
CHANNEL 9: Shutter / Strobe (0-13Hz), and Shutter close/open function + random strobe
CHANNEL 10: Dimmer (Intensity) Control
CHANNEL 11: Color Temperature
CHANNEL 12: Special / Reset
CHANNEL 13: Movement Macros
CHANNEL 14: Speed Control (Pan/Tilt movement)
Normal Mode - 14 DMX Channels
Channel
Function
Time and Value
DMX
HEX
%
1) Pan Coarse
0 .. 660°
Min. 3.2 s
0..255
00..FF
0..100
2) Pan Fine
High- Pos ... High- Pos + 2.6° (16 Bit)
0..255
00..FF
0..100
3) Tilt Coarse
0 .. 300°
Min. 1.5 s
0..255
00..FF
0..100
4) Tilt Fine
High- Pos … High- Pos + 1.2° (16 Bit)
0..255
00..FF
0..100
5) Color Wheel
Colors adjustable via RGB
0..7
00..07
0..2.5
(Fixed)
Color 01 – Red 1)
8..15
08..0F
3..5.5
Color 02 – Amber 1)
16..23
10..17
6..8.5
Color 03 – Warm Yellow 1)
24..31
18..1F
9..12.5
Color 04 – Yellow 1)
32..39
20..27
13..15.5
Color 05 – Green 1)
40..47
28..2F
16..18.5
Color 06 – Turquoise 1)
48..55
30..37
19..21.5
Color 07 – Cyan 1)
56..63
38..3F
22..24.5
Color 08 – Blue 1)
64..71
40..47
25..27.5
Color 09 – Lavender 1)
72..79
48..4F
28..30.5
Color 10 – Mauve 1)
80..87
50..57
31..34.5
Color 11 – Magenta 1)
88..95
58..5F
35..37.5
Color 12 - Pink1)
96..103
60..67
38..40.5
White – CTO
Color temperature @
3200K
104..111
68..6F
41..43.5
