11
STARTUP VIEWS
There are 5 different status screens (see images below) visable when device is connected to a
powered POE source. Select/switch screens by pressing the UP or DOWN buttons.
1. Device Name - This displays the current name (16 characters max).
SYSTEM MENU UPDATE WITH SOFTWARE UPDATE VERSION ≥1.3
The menu item below has been added with this software update.
2. MAC Address - This displays the current MAC Address.
Press and hold the ENTER button to access the MAC Address menu to make changes.
3. IP Address - This displays the current IP Address.
4. Device ID - This displays the current Device ID.
5. Port Status - This displays the status of each port 1 and 2.
O = DMX Output
I = DMX Input
✔
= Network Active
✕
= Network Inactive
H = Hold
B = Blackout
- = Not Allowed
eNode 2 POE
5E:D2:78:54:52:12
002.010.010.002
001
Port Status
1
2
0
X
H
001
0
X
H
001
