15 EMOTION™ User Manual Ver. 1
ELATION© EMOTION™ S Y S T E M M E N U
Specifications and features are subject to change without any prior written notice.
MAIN MENU SUB MENU OPTIONS / VALUES (Default Settings in BOLD) DESCRIPTION
Test
Home
All Reset All Motors
Pan&Tilt Reset Pan/Tilt
Others Reset Others
Test Channel PAN …… Test function
Manual Control PAN =XXX, ......
Fine Adjustments
Calibration Calibration Password Password 050
Mode Set
Standard Mode
DMX Channel Modes
Extended Mode
Preset
Play Back
DMX Control DMX Control
Set To Slave Slave1, Slave2, Slave3 Salve Mode
Auto Program Master / Alone Auto Program
Select Prog.
Prog. Part1 = Program 1~10 (Program 1)
Select Programs To Be Run Prog. Part2 = Program 1~10 (Program 2)
Prog. Part3 = Program 1~10 (Program 3)
Edit Prog.
Program 1 Program Test Testing Program
: Step 01=SCxxx Program In Loop
Program 10 Step 64=SCxxx Save and Exit
Edit Scenes
Scene 001
~
Scene 250
Pan,Tilt,…… Save and Automatically Return
--Fade Time--
Manual Scenes Edit
--Scene Time--
Input By Outside Stores Scenes via Ext DMX Console
Scenes Input XX~XX Automatic Scenes Recorder
Test – Calibration
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION.
This function allows small adjustments to be made to the fixture to compensate for
ware or in the event a sensor has been knocked slightly out of place. Because
improper use of this function can result in undesired operation this function has been
password protected. The password is 050 and must be entered each time the
calibration menu function is entered. Because calibration is an extremely delicate
procedure, instructions on performing this action are left out of this manual. For a first
time calibrator, please contact our customer support team for step-by-step
instructions.
